The DCL/DCLE cores consist of 80% molecular sieve and 20% activated alumina, designed for systems that operate at high condensing temperatures and require high drying capacity. The shells are PED approved for PS 46 bar (DCL) and PS 50 bar (DCLE), and come with options for solder (Cu-plated steel connectors) or flare connections. They have a corrosion-resistant powder-coated finish, with a special coating available for marine applications. The filters feature a 25 μm retention with minimal pressure drop and are thermally stable up to 120°C.


Features

The Core type DML/DMLE
• 100% Molecular Sieve core.
• High drying capacity minimizing the risk of acid formation (hydrolysis).

The Core type DCL/DCLE
• 80% Molecular Sieve with 20% activated alumina.
• Perfect core blend for systems that operate at high condensing temperatures and require high drying capacity.

The Shell
• DML and DCL are PED approved for PS 46 bar.
• DMLE and DCLE are PED approved for PS 50 bar.
• Available with solder (Cu-plated steel connectors) and flare connections.
• Corrosion resistant powder-painted finish. Special coating for marine applications available upon request.
• Allows installation with any orientation provided the arrow is in the flow direction.
• Available in sizes 1.5 – 75 cubic inches.

The Filter
• 25 μm (0.001 in.) filter provides high retention with minimal pressure drop.
• Thermally stable up to 120 °C.

Infomation to order the product/Thông tin liên hệ mua sản phẩm:
HVACR VIET NAM ENGINEERING CO.,LTD/ CÔNG TY TNHH KỸ THUẬT HVACR VIỆT NAM
Address: 331/70/45A Phan Huy Ich Street, Ward 14, Go Vap District, HCM City, Vietnam
Telephone/ Điện thoại: (+84) 327.299.154
